At flywheel 55 HP/DIN

Engine:

Fiat 8035.06, 4 - Stroke, 3 Cylinders
Direct Injection Diesel,
Max. Power:     2500 rpm 55HP/DIN (41.0 kw)
Max. Torque:    1500 rpm 185NM (18.88 Kgm)
Bore & Stroke: 100 x 115 mm.
Piston Displacement:    2,710 cc.
Compression Ratio:     17:1
Four-Bearing Crankshaft
12 Volt Starting System; 4 hp Motor
400 Watt Alternator
88/92 Ah Battery
Gearbox Mounted Starter Safety Switch
Vertical Exhaust Muffler

Operating Weight:

1,710 Kg with 6.00-16 and 12.4/11-28 Tyres,

Transmission:

Gearbox with Constant-Mesh Gears
Gears:         8 Forward 2 Reverse Speeds
Synchromesh: 3rd, 4th, 7th, and 8th Speeds
Differential with Pedal Actuated Lock
and Automatic Disconnection.
Single-Reduction Spur Gear Final Drives.


13/8” – 6 Spline Shaft
Fully Independent: 540 rpm at
2,160 Engine rpm
High-Speed  PTO* (13/8” shaft)
Same Speed as Engine.

* Depends on belt pulley

Dimensions:

(with 6.00-16 and 12.4/11-28 tyres)

Wheelbase:                          1,920mm
Overall Length:                   2,960mm
Height to Top of Hood:       1,390mm
Height to Steering Wheel:  1,490mm
Front Tread (8 positions):   1,320 – 2,020mm
Rear Tread (8 positions):    1,200 – 1,900mm
Ground Clearance:              480mm under
                                              Front Axle
